Titanium ring whose jewels glow through induction


Ben Kokes wanted to give a ring to his sweetheart, and to make it interesting, he decided to create a ring with an inductive loop that would cause the stones to light up when they were close to a power-source. He documented the tricky technical problems that cropped up during the build, and it sounds like the romance part came out well, too:

The final idea was to embed a LED and copper coil assembly inside the titanium ring, illuminating it from under the stones when it was in close proximity to an induced alternating magnetic field (henceforth called 'the transmitter'). Autodesk Inventor helped me develop all of the dimensions and constraints for the design. Having some help, I was able to obtain her ring size and the rest of the measurements were based from there (15.72mm if anyone was wondering)...

... Of all the challenges presented in making the ring, affixing the stone is the most difficult. Traditionally, stones are affixed by mechanical means -- prongs, groves or snaps. Epoxies will delaminate from the attachment surfaces due to microstresses, thermal cycling, and other unmentioned movements. The stone may be attached now, but eventually it will fall out. It's just a matter of time.

With that in mind, I had 4 initial ideas for affixing the stone: thermally expanding the hole, hole deformation, point expansion deformation, and epoxy. Ultimately, I went with the epoxy method for attaching the stones.

The first test was to try and heat the ring, expand the hold and drop in the stone. When the hole cooled and contracted, it would hold the stone in place. Not only does the hole not expand enough, if I was lucky enough for it to happen (it did once), the stone would fracture along pre-existing crack lines.

Project Longhaul (via Hacker News)

Contest: design peaceful uses for 3D printers

Bas writes,

3D printing is being condemned in the media because of the potential for printing guns. Engineers at Michigan Tech believe there is far more potential for 3D printers to make our lives better rather than killing one another. To encourage thinking about constructive uses of 3D printing technology Michigan Tech Open Sustainability Technology (MOST) Lab and Type A Machines is proud to sponsor the first 3-D Printers for Peace Contest.

A fully assembled Type A Machines Series 1 3D Printer goes to first place and a MOST RepRap 3D printer kit will go to the second prize winner who create designs that enable 3D printers to encourage peace. Winning open-source designs will discourage conflict (e.g. designs for appropriate technology in the developing world to reduce scarcity or designs that improve economic development -- see examples and pictures). Designers are encouraged to consider: If Mother Theresa of Ghandi had access to 3D printing what would they print? What kind of designs could help reduce military spending and conflict while making us all safer and more secure?

Michigan Tech has already saved tens of thousands of dollars using 3D printable scientific and engineering equipment and our labs have developed 3D printable tools to test water quality, recycle waste plastic and found that 3D printing consumer goods is better for the environment than shipping conventional goods from China. Jo

Anyone in the United States may enter and there is no cost to enter. Here's the guidelines. Deadline for submitting entries: September 1, 2013

Michigan Tech Launches 3D Printers for Peace Contest

Boba Fett mixer


DeviantArt's TommyFilth modded a KitchenAid mixer and gave it a perfect Boba Fett makeover: "I asked for a Kitchenaid mixer for Christmas, I pointed my wife toward a broken one on eBay so that I could refurbish it, as I was taking it apart I got some inspiration for the paint job and this is what came out of it, still needs a phase board for speed control and two decals to be applied to the sides but I couldn't wait to share."

Boba Fett Mixer (Thanks, Fipi Lele!)

Face morphing mirror at Maker Faire 2013

One of my favorite exhibits at Maker Faire Bay Area 2013 (held last weekend) was Alex Andre's Metamorphosis Project. It's a six-foot-diameter spinning disc with a hand crank. The disc is made of clear glass and mirrors in alternating quadrants. You stand on one side and line up your nose with a person standing on the other side. As the disc spins, you see a rapidly flickering image of your reflection and the other person's face. The effect was hallucinatory - I not only saw my face merge with the other person's face, but I also saw faces pop in and out that looked nothing like either of our faces. These videos give you just a small taste of the trippiness. I hope you get a chance to experience it yourself one day.

Modified Liberator 3D printed gun made with cheap printer, fires 9 shots

Joe, an engineer from Wisconsin, modified the (now censored) designs for Defense Distributed's 3D printed gun, the Liberator, and printed a working model on a Lulzbot A0-101, a $1,725 consumer printer that is much cheaper and more widely available than the Stratasys Dimension SST printer used by Defense Distributed.

The gun printed by Joe, which he’s nicknamed the “Lulz Liberator,” was printed over 48 hours with just $25 of plastic on a desktop machine affordable to many consumers, and was fired far more times. “People think this takes an $8,000 machine and that it blows up on the first shot. I want to dispel that,” says Joe. “This does work, and I want that to be known.”

Eight of Joe’s test-fires were performed using a single barrel before swapping it out for a new one on the ninth. After all those shots, the weapon’s main components remained intact–even the spiraled rifling inside of the barrel’s bore. “The only reason we stopped firing is because the sun went down,” he says....

...Still, Joe’s cheap homemade gun isn’t without its bugs. Over the course of its test firing, Joe and Guslick say it misfired several times, and some of its screws and its firing pin had to be replaced. After each firing, the ammo cartridges expanded enough that they had to be pounded out with a hammer. “Other than that, it’s pretty much confirming that yes, Defense Distributed is correct that this functions,” says Guslick. “And it’s possible to make one on a much lower cost printer.”

$25 Gun Created With Cheap 3D Printer Fires Nine Shots (Video) [Andy Greenberg/Forbes]

Pancake arthopods


Pancakeist Nathan Shields polled his pals for their favorite athropods and then recreated them in pancake form. Crunchy!

Favorite Arthropods 1 (via Neatorama)

Patent lawyers: Help! The evil Makers won't let us apply for bullshit 3D printing patents!

Two minor characters from my novel Makers have apparently come to life and written an article for 3D Printing Industry. These two people are patent lawyers for Finnegan IP law firm, Washington, DC, which I don't recall making up, but this is definitely a pair of Doctorow villains (though, thankfully, I had the good sense not to give them any lines in the book -- they're far too cliched in their anodyne evil for anyone to really believe in).

These patent lawyers are upset because the evil Makers (capital-M and all!) are working with the Electronic Frontier Foundation to examine bad 3D printing patents submitted to the US Patent and Trademark Office. The problem is that 3D printing is 30 years old, so nearly all the stuff that people want to patent and lock up and charge rent on for the next 20 years has already been invented, and the pesky Makers are insisting on pointing out this inconvenient fact to the USPTO.

This breaks the established order, which is much to be preferred: the UPSTO should grant all the bullshit patents that companies apply for. The big companies can pay firms like Finnegan to file patents on every trivial, stale, ancient idea and then cross-license them to each other, but use them to block disruptive new entrants to the marketplace. The old system also has the desirable feature of arming patent trolls with the same kind of bullshit patents so that they can sue giant companies and disruptive startups alike, and Finnegan can be there to soak up the tens of millions of dollars in legal fees generated by all this activity.

Can't these darned Makers understand? The point of a patent isn't to protect novel, useful inventions! It's to put the brakes on out-of-control innovation and to ensure that the children of the partners at Finnegan can go to a good college! What will happen to GDP if we divert money from the honest business of barratry and allow it to be squandered on making and selling stuff that people find useful?

The America Invents Act changed U.S. patent law to allow preissuance submissions, a mechanism by which third parties can submit patents or printed publications to the United States Patent & Trademark Office (USPTO) for consideration during patent examination, along with “a concise description of the asserted relevance of each submitted document.”[2] The U.S. Congress intended preissuance submissions to help the USPTO increase the efficiency of examination and the quality of issued patents.[3] Congress did not, however, intend the use of this mechanism to interfere with patent examination.[4] Nor did it intend preissuance submissions to allow for third party protest or preissuance opposition.[5] Yet a segment of the 3D printing (3DP) community, known as Makers, is using preissuance submissions as a sword to oppose 3DP-related patent applications. Perhaps more importantly, they are leveraging the concept of crowdsourcing to do so, potentially creating problems for patent applicants everywhere.[6]

To understand why and how Makers are mobilizing to challenge patents through presissuance submissions, one must first understand what 3DP is, and the composition of the 3DP community. 3D printing—more formally known as additive manufacturing—is a technology that creates three dimensional objects from CAD files. There are many legacy and emerging 3DP technologies. Generally, 3DP works by fusing layer upon layer of materials, such as plastics, powder metals, and ceramics, to build a final, fully formed product, much as Athena sprung full-blown from the head of Zeus. This process requires a digital 3D model of the product, stored in a CAD file, and a 3D printer. Digital product models can be obtained by either (1) designing the product with a CAD program; (2) downloading an existing CAD file from the Internet; or (3) scanning an existing product with a 3D scanner to create a CAD file. Further, almost anyone can buy a 3D printer today; they are sold through Skymall and at Staples. Where 3DP was once cost prohibitive for most, ‘prosumer’ and home printers are now available at reasonable prices.

Crowdsourcing Prior Art to Defeat 3D Printing Patent Applications

(via Beyond the Beyond)

(Images: Caricature of William Otto Adolph Julius Danckwerts, Caricature of Charles Russell, Leslie Ward/Vanity Fair/Wikimedia Commons)

11 year old and his 3D printer

Alex sez, "My colleague Chris Neary and filmmaker Nathan Fitch made this great short film about 11-year-old inventor Andrew Man-Hudspith, who was so intent on getting a 3D printer he made a PowerPoint presentation to convince his parents to help him get one."

An 11-year-old and his 3D printer (Thanks, Alex!)

Printing a gun is hard

Caleb sez, "The Department of Defense ordered that 3d printed gun removed from the Internet. That didn't work out. You can still download it and print it. I did, and found that the files are a mess and not really functional. I also took a cool timelapse video of the printing."

1. the scale on the individual files was way off.

I suspect this has something to do with the printer it was designed for. It seemed very close to being 1 inch = 1 mm. Not a completely uncommon problem. Manually resizing got some files to look right, but I found many simply wouldn’t resize.

2. Almost every single item had errors.

If you’ve done 3d printing, you’ve found that a model can have all kinds of issues that will stop it from printing correctly. I found every single item for the gun had errors. I actually learned a lot about how to repair non-manifold items from this exercise, so it was good in the end.

Some items, like the hammer and the hammer springs simply would not print. I ran them through systems to repair them and fix errors. It would say that everything was fixed, but when I tried to “slice” them for printing, the software would crash. This means that my gun is incomplete. It has no hammer. Not really that big of a deal to me.

Timelapse of the 3d printed gun being printed. (Thanks, Caleb)

3D printing for kids, this weekend in Toronto!


Back in January, I blogged my visit to Toronto's MakerKids, a wonderful makerspace for kids. Now, MakerKids is running a 3D printing weekend for kids at Toronto's Harbourfront centre. Andy from Makerkids writes, "This weekend, at the 11th annual Toronto International Circus Festival (from May 16th-18th at the Harbourfront Centre), MakerKids will be helping kids to do 3D printing of circus creatures! At our station at this free event, kids will design fantastical animals and characters they'd like to see in a circus using the 123D Creature app. The crowd's favourites will be 3D printed for their designers to bring home!"

MakerKids 3D Printing at Harbourfront this Weekend (Thanks, Andy!)

HOWTO make glowing Converse

The good people at Adafruit have an easy way to make your Chucks glow!

Make your logo light up with this simple Converse sneaker mod. All you need is EL panel and an inverter tucked into the tongue of your shoe to get the stars in your Chuck Taylors glowing. Two styles!

Glowing Star Chuck Taylor Sneakers

Glowing algae make a nice nightlight

This is a picture of a wave crashing on the New Jersey shore. It glows because of dinoflagellates — little, single-celled plants, animals, and bacteria that float around on the water, moving about with the help of long, moveable protein strands called flagella. Some dinoflagellates are bioluminescent; that is, chemical reactions inside their bodies produce light. The result is glowing oceans. Or, as maker Caleb Kraft recently discovered, the dinoflagellates also make for a soft blue nightlight with really nifty special effects.

You can watch Kraft's nightlight project at YouTube. It's pretty simple to do at home. At it's most basic, all you need to do is purchase some bioluminescent dinoflagellates online, keep them alive in your home, and give them a good shaking occasionally to trigger the chemical reaction.

A couple more helpful links:
Where Kraft bought his dinoflagellates
• A guide to other dinoflagellate dealers, and to the care and feeding of unicellular organisms
• Researchers at the Scripps Institution of Oceanography who are studying dinoflagellate bioluminescence to better understand how it works and what role it plays in the ecosystem
A detailed explanation of what dinoflagellates are and why they glow

Via Treehugger

Image: Red Tide Luminescense, a Creative Commons Attribution (2.0) image from piratelife's photostream

It's a face! A skull! A mushroom! Psychedelic drawing lesson

Katana Leigh sez, "I want to provide memorable ways to learn to draw that are interesting and visually entertaining. The proportions of a red spotted button mushroom are the same as a skull and these LSD colors provide maximum contrast so you can see the process and hopefully copy it. Not your boring art lessons but a new way to think about seeing."

How To Draw A Skull 2: when a mushroom is like a face (Thanks, Katana!)

Self-assembling foldable inchworm robots

Here's a quick and fascinating look at "Robot Self-Assembly by Folding: A Printed Inchworm Robot," presented at the 2013 IEEE International Conference on Robotics and Automation. The authors demonstrated a foldable inchworm robot that actually folds itself into shape. The goal is to have all the components placed on the robot's shrinky-dink surface using a robotic pick-and-place machine, so that the inchworm robots can be produced, assembled, and set a-inching on their way without human intervention.

The tricky part of the process is the folding of the robot itself: installing the battery and motor is trivial enough for a human to do, which means that a relatively simple pick and place robot should have no problems doing the same thing. This means that these robots have the potential to scale massively: they can be printed out of cheap materials, they fold themselves together, and another robot can plonk some hardware on them and they’re good to go.

This Crawling Inchworm Robot Can Be Printed Out and Folds Itself [Evan Ackerman/IEEE Spectrum]

(via Beyond the Beyond)

Skittles sorting machine, version 3

Here's Brian Egenriether's new-and-improved Skittles sorting machine. It's interesting to note that he used machinable epoxy for the parts instead of using a 3D printer. I know 3D printing is the future, but the current crop of home 3D printers make ugly parts. Subtractive fabrication technology makes better looking stuff, at least for now.

This machine sorts Skittles, m&m's and similar candies by color. It is the 3rd revision of the original machine. The inside is now complete and features user-selectable inputs to choose which type of candy to sort. Types not shown include Reese's Pieces and other types of Skittles.

The microcontroller is a BASIC Stamp 2 and the color sensor is made by TAOS. I made most of the parts by hand from a machinable epoxy including the outer case, inner housing, hopper mechanism, 5 way chute, and the the rotating disk inside. The other parts include a piece of PVC, ceramic bowls, telescope parts, wood for the base, and the funnel which was cut from a hummingbird feeder.

Automatic Sorting of Skittles or M&Ms by Colour (Thanks, D.S. Deboer!)
