Crowdfunding Novena, the fully open/transparent laptop project

Remember Bunnie Huang's fully open laptop? Bunnie and Sean "xobs" Cross prototyped a machine he called the "Novena" in which every component, down to the BIOS, was fully documented, licensed under FLOSS licenses, and was totally modifiable by its owner.

Now, Bunnie and Xobs have teamed up with Sutajio Kosagi for a crowdfunding campaign to take the laptop into production. $500 gets you the board, $1200 gets you a desktop version, $2000 gets you a laptop and $5000 get you a "heirloom laptop" in a handmade wooden case crafted by Portland-area luthier Kurt Mottweiler.

The Novena is "not a device made for consumer home use" -- it has lots of components that are exposed during normal use, has no moisture- or static-resistance built into it, etc. It's intended as a piece of high-quality lab equipment for people interested in the long-term project of building fully open, everyday use computers where surveillance, abusive commercial practices, and other proprietary horribles are substantially harder to accomplish than in the current hardware/software ecosystem.

Noah Swartz notes, "I for one am super excited about it because it's meant specifically for hackers and tinkerers. The motherboard has a Spartan-6 CSG324-packaged FPGA built right into it, and if you opt for the conversion-tablet form factor you also get bunni's own battery controller which allows you to use cheap RC car or airplane batteries instead of expensive laptop specific ones by moving the load balancing circuits off of the battery itself. Also the internals of the case are covered in mounting holes (dubbed the peek array after Nadya Peek: https://www.youtube.com/watch?v=iIUE8VVLjCE) which allow you to affix whatever sort of add-ons you want to the inside of the laptop."

I've put in for one of the laptops. I can't wait.

Read the rest

Arduino-powered Etch-a-Sketch clock

Dodgey99 built an Arduino-powered Etch-a-Sketch clock, in which a pair of stepper motors painstakingly draw out the current time. It's got a very low refresh rate, though: the limits of the motors and the Etch-a-Sketch means that it takes more than a minute to display the time, and it needs a couple of minutes' rest between each number. There's a plan to accelerate things with some beefier motors.

I use an Arduino driving two very cheap darlington stepper drivers with 64:1 internally reduced steppers for the drawing. For the rotation I'm using an Easy-Driver driving a Nema 17 stepper.

I also have a DS1307RTC real time clock installed so it always knows the time. Setting the time is a one-off via USB connected to a PC. Once done, you un-tether, and then the RTC keeps the time, for up to a year on the rechargeable battery, or so I'm told...

The code is actually very simple, it's just a pain drawing the numbers!

The G clamp on the back is for a counter balance until I find something more elegant!

The steppers are far too slow to write the time in under a minute so I delay it for a couple of mins between each draw. Mostly to give the very hot motors a while to cool off and to give the etch a sketch a break!

Etch a Sketch clock powered by Arduino (via JWZ)

Open source soft robotic quadruped with many applications

Pt and Limor write, "The Glaucus, named after the Blue Sea Slug (Glaucus Atlanticus), is an open source soft robotic quadruped from Super-Releaser. It is a proof of concept for a method developed at Super-Releaser that can reproduce nearly any geometry modeled on the computer as a seamless silicone skin. The company hopes to apply these same techniques to practical problems in medicine and engineering as the technology develops. The quadruped has hollow interior chambers that interdigitate with one another. When either of these chambers is pressurized it deforms and bends the structure of the robot. This bending produces the walking motion. It is similar to how a salamander walks, by balancing itself on one pair of legs diagonal from one another while moving the opposite pair forward."

Read the rest

Eggbot design: Pi Egg for Pi Day


Tomorrow, 3/14, is Pi Day in the USA (it will not be Pi Day in the rest of the world until the Martian Emperor subjugates us all to his sinister 14-month calendar). In celebration, Thingiverse user Thor4231 posted this great Eggbot design, ready to be automatically sharpied onto your favorite ovum by means of the wonderful Eggbot printer.

Pi Egg for Pi Day

Crowdfunding a smart, open source beehive to monitor hive-collapse

Tristan writes, "The Open Source Beehives project is a partnership between the Open Tech Collaborative and Fab Lab Barcelona crowd-sourcing a solution to the bee colony collapse issue.

Read the rest

Kickstarting an Arduino-based Enigma machine

ST Geotronics have exanded their Instructables project for building your own Arduino-based Enigma and turned it into a Kickstarter. $40 gets you some boards you can kit-bash with; $125 gets you the full kit; $300 gets you the whole thing, beautifully made and fully assembled.

The Open Enigma Project (Thanks, Tina!)

HOWTO make glowing, 3D printed cyberpunk spikes

Phil and Limor from Adafruit write, "Make your own flexible, spiky, glowing accessory using NeoPixel strip diffused by NinjaFlex flexible 3D printing filament! Magnets let you attach the spikes to anything in your wardrobe. The soft flexible enclosure holds GEMMA, the tiny microcontroller that animates the LEDs, and a rechargeable lipoly battery."

Cyberpunk Spikes (Thanks, Pt and Limor!)

HOWTO build a robotic air-hockey opponent out of Reprap parts

Jose Julio realized that the drive-train and parts in a Reprap printer could be repurposed, along with an Arduino-controlled vision-system to create a robot air-hockey opponent. He documented the build here, and the code is on Github.

Read the rest

Build your own open source hardware Nest-style smart thermostat


Alan sez, "Spark.io provides instructions for making your own Nest-like 'smart' thermostat. Of course it's entirely open source, with files on github."

Read the rest

Storefront pixel-art video-game for the neighbourhood


Last November, Kris Temmerman decided to outfit the empty store-window of his Antwerp flat/studio as a playable video game for his neighbours to play as they passed by. He wrote his own Arduino-powered pixel-art game and set some controllers into the exterior window-frame and watched what happened. It turned out great, and Kris has thoroughly documented the build and released his source so you can try it too.

Read the rest

Building a fully open, transparent laptop


Bunnie Huang is a virtuoso in hardware engineering, and a hero of the open source hardware movement. In this Make post, he documents how he and Sean "xobs" Cross prototyped a laptop that was open and transparent to a very great degree, secure against all attacks short of dopant-level hardware trojans. The post -- and the photos of the gloriously fuggly laptop, which they dubbed "the Novena Project" -- is part requirements document, part philosophical statement, and part engineering text. I love Bunnie's reasoning for wanting an amazing, open laptop: he spends the majority of his waking hours with it, so he wants it to be as amazing as possible, and it's worth him spending the time and money to get there. I also love the requirements he sets out for genuine "openness" (I put some of these after the jump, below). Most of all, I love how this thing looks: rough-hewn, gloriously unfinished with its 3D printed panels, and as bursting with potential as the Colossus.

Read the rest

3D printed, trainable robot arm with Arduino controller

Joly sez, "Maker navic09 demos a prototype trainable robotic arm, made from 3d printed parts, an Arduino, and Adafruit analog feedback servos. Inspired by the Baxter robot, this arm can be trained to move with your own hands. Once the train button is pressed, you move the arm and gripper as needed while the Arduino stores the positions in EEPROM. After that the arm will replay the motion as needed."

The gripper and arm are on Thingiverse.

Trainable Robotic Arm 1 (Thanks, Joly!)

Hauntbox: open-source hardware box for controlling your automated, electronic haunted house

The Hauntbox is an open-source hardware controller for all the sensors and controllers necessary to build sophisticated, automated electronic haunting projects. It requires no soldering or prior knowledge to use, and is fully hackable and accepts Arduino shields. The Kickstarter was successful, and they've gone into full production: you can pre-order them for next Hallowe'en now.

Hauntbox.net (via Make)

Seej: a 3D printed, free real-world tower defense game


Zhreng3's Seej is a free/open 3D printable tabletop war-game, a real-world tower-defense game you print and play at home. Seej's players come up with all sorts of innovations that are integrated into a constantly updated set of free designs.

Read the rest

Crowdfunding a 3D printed, open source hardware robotic/prosthetic hand

The Dextrus is crowdfunded, production version of the Open Hand, a 3D-printed, open source hardware prosthetic/robotic hand that is freely licensed and patent-free. They're raising money on indieGogo to do a production run -- £460 gets you a fully assembled hand; £700 gets you the hand with all electronics.

Read the rest
